FB-350 & FB-430

Your Starting Line for High Performance

The FB-Line represents a highly efficient label printing press. Nilpeter has added a large number of innovative features and packaged the press in an attractive design. The FB-Line is has increased automation, higher ease of use, and operator friendliness.

The FB-Line comes with a number of added features, such as Automated Plate Positioning System (APPS), pre-register and re-register functionality.  The FB-Line is designed to print value-added labels in the most efficient way at high speeds. While this press looks entirely different, it will still feel intuitive to the printer already accustomed to work on existing FB-Lines.

The joy of operation

The FB-Line is a sophisticated workhorse offering high ease of operation and superior printing quality. Increased operator friendliness is a central element in the design process for Nilpeter’s FB-Line. The flexo press is extremely simple to manage, even though we have added a number of technology advancements.

Opportunities

Available in 13” and 16” widths, the FB-Line is the perfect choice for the flexible label printer. The flexo press is designed to deliver maximum flexibility at an affordable price.

The printer can customise the press to meet a vast number of requirements – from a very basic to an advanced configuration. Innovative automation features can be added according to requirements and combined with value-added features, such as lamination, cold foil, hot foil, gravure, and screen printing.

FB-Line Specifications

Metric
Imperial
Model
General
Press speed:
228 m/min. mechanical speed
750 FPM
Web
Unwind diameter:
1016 mm, max 226 kg
40″, max 226 kg
Rewind diameter:
1016 mm, 226 kg
40″, 226 kg
Waste rewind diameter:
1016 mm, 40 kg
40″, 40 kg
Printing
Web width:
350 mm
13 3/4”
Print width:
350 mm
13 3/4”
Die-cutting width, max.:
350 mm
(13 3/4”)
Flexo, repeat length:
177,8-609,6 mm
7″-24″
Screen, repeat length
304,8 – 457,2 mm
12″-18″
Die-cutting repeat length (conventional)
203,2-609,6 mm
8″-24″
Hot foil repeat length
222,25-457,2 mm
8 3/4”-18″
General
Press speed:
228 m/min. mechanical speed
750 FPM
Web
Unwind diameter:
1016 mm, max 340 kg
40″, max 340 kg
Rewind diameter:
1016 mm, 340 kg
40″, 340 kg
Waste rewind diameter:
1016 mm, 40 kg
40″, 40 kg
Printing
Web width:
425 mm
16 3/4”
Print width:
425 mm
(16 3/4”)
Die-cutting width, max.:
425 mm
16 3/4”
Flexo, repeat length:
177,8-609,6 mm
7″-24″
Screen, repeat length
304,8 – 457,2 mm
12″-18″
Die-cutting repeat length (conventional)
203,2-609,6 mm
8″-24″
Hot foil repeat length
254,25-457,2 mm
10”-18″
FB-Line

Download the brochure

The essential features and overview in one document
